Create a Balsa Bridge able too withstand at least 100lb of pressure from the middle of the bridge from a 2*2 surface area

simulating the force on the table legs from a toddler

This is an air filtration unit that I have already build.
It consists of 2 filters, a 3rd one to be added.
HEPA F7
HEPA H14
the HEPA G4 filter needs to be added.
It also uses a CA/LINE31 Centrifugal inline FAN
And at the exit, it has a 20mm thick 6.4mm hole opening  Aluminium Honeycomb.
The Box is out of wood and actually is a crate :)
The measured airflow at teh face is just below 1m/s
