External hydrodynamics of a bouy cylinder-shaped.

simulation of pressure drop through the pipe lyre

Calcular las fuerzas que ejerce el agua sobre el rodete

Se busca visualizar el perfil de velocidades que se generan dentro de una carcasa

Se desea observar el flujo atraves de una carcasa con un rodete adentro

Visualizar el flujo de agua sobre esta carcasa

USV Balancing System with Operculum  moving mass control simulation

This project is for school and were going to use the fluid simulation for pressure. the goal of this project is to create a device which involves pressure and temperature

To analyze the fluid flow (p) of the drainage and planning sedimentation plot positions.

water flow in a convergent-divergent nozzle.

Quick assessment of the water level of a cooling tower water distribution open channel.
Multiphase flow. constant density, no energy equation.
The channel has a water inlet and numerous holes for outlet, while it is open to the atmosphere.

Test of obstacles in pipe water flow for hydroelectric plant

This is a check valve run without the check ball

Turbine type  Archimedes Screw
1 (No of helix)
No of blades 20
Head 1 m
Optimum angle 18 degree  referred from journal in internet
Length of the turbine shaft 3000
Geometry Details(dimension in mm)
Flow domain is cylinder dia (1200) length (3600)
MRF Volume cylinder dia(1100)  length(3400)
Turbine OUTER dia (1000) INNER dia(shaft dia) (400)
Total shaft length (3200)

Flow analysis of C12 Basic Model of Valve in sphere

Temperature distribution through a U-type heat exchanger.

In this project incompressible fluid flow simulation of a conical draft tube is carried out. The parameters data is collected from the course book on fluid dynamics and the validation of CFD simulation result with the theoretical result is also performed. Steady state incompressible fluid flow simulation is selected for the given case.
The draft tube is a pipe of gradually increasing area, which connects the outlet of the water turbine's runner to the tail race. Draft tube helps to convert the exit velocity head into pressure or potential head.

This project involves meshing internally a Ball Valve, and then simulating its' operation when water flows through it. A ball valve is a structure that is placed between two pipelines, connecting them through its' hollow interior by utilizing two diametrically placed holes. For this case, the floating ball has a hollow cylinder through its center, with a diameter same as the inner one of the pipelines. The Cylinder is not parallel to the pipes, and instead it is placed diagonally. A steady state incompressible flow simulation is executed to visualize the flow and its' re-circulation, as well as the critical areas of the pressure drop.

this is a waterblock for cooling my Raspberry pi 4

DETERMINE ENERGY LOSSES IN A CLOSED LOOP PIPE

Simulation of Weir Structure Under Various Mass Flow

Project does contain examples of SimScale problems with features / simulations
