This project involves the simulation of stress analysis of an aircraft wing. There are total 6 comparison configurations with 3 different models and two different load definition.

This project demonstrates the hip joint prosthesis for the femur bone. Several types of materials are tested for the hip joint in this case including Co-Cr-Mo on Ti-6Al-4V, Co-Cr-Mo on UHMWPE and Concrete on Concrete.

In this project drop of a drone on a rigid plate was simulated.

Original project of @rszoeke

This is a demo of stress concentration for a strengths of materials class.

In this project a nonlinear static structural analysis of a hand tool is demonstrated.

Stress analysis of leaf-spring under different loads (40N, 100N, 1kN)

This is an example of analyzing a sheet metal box in simscale. Ideally we would like to use Shell elements but it can be done with Solid elements as well. In this example we look at the effects of a sheet metal with and without ribs as well as validating the accuracy of the model.

Please see the Comments Section for more details on this Analysis.

Response of a crane structure to tip load

Simple transport bracket to lift a 160kg injection moulding tool.

A snap-fit is analyzed using a dynamic stress simulation including physical contact between two parts.

This project shows the bending of the copper beam done through a half ring mold.

A bottle opener is simulated before sent to the 3D printer to ensure its performance.

In this project tension, torsional and bending load tests of a hyperelastic rubber bellow is performed.
