This simulation project aims to show the buckling of the column whose one end is fixed and force applied on the other end.

This project is aims to optimize a wing rib where it present a several shape of cut-outs deal. This ribs is made from Aluminium and the applied force on the wing rib is 10 KN vertically and its attachment will be fixed. This process will help to improve and optimize the ribs design.

This project aims to find out the hot spot in the design of the pipe bend at the connecting point. The pipe bend is made of the steel and a pressure of  2000 Pa , 3000 Pa and 5000 Pa will be applied and the joint will be fixed. This process will help to improve and optimize the design of the Pipe Bend.

To analyze the stresses present in a simple cantilever problem through FEA. Geometry being used is  of a pipe

The main aim of the project was trying to find stress and total displacement on the surface and check with experimental results. In this project, F1 halo is simulated in two different static load condition and for that use SIMULATION TYPE was STATIC. The halo is a driver crash protection system used in open wheel racing series which consists of a curved bar placed to protect the drivers head. The system was introduced in 2015 and became mandatory according to FIA homologation and regulation from 2018.

Stress response of tooth during mastication (chewing).

analizzare stess dovuto alla compressione senza supporto di alluminio

Analisi della deformazione a seguito di compressione

Static Structural Analysis of a gear assembly.

model behavior of a string of beams with continuous and punctual loads and determine contact points with another other geometry.

Large Structure- Static Structural Analysis

This work aims to present the use of FEM in the analysis and design of an auxiliary device for the torque of the piston fixing nuts in hydraulic cylinders.

The goal is to investigate several case studies in automotive components. This includes:
- mechanical stress simulations
- thermal simulations
- CFD simulations

A simple simulation of  a die forming process.

The aim is to dimension the mast of a light pole of 11 meters high with variable diameters. The implementation of the project will be in the patio of Raízen in Marabá-BR, located on the railroad.

The strength of components is an important requirement in understanding a products performance lifecycle and possible failure modes. Tractors and other agricultural equipment are used in rough terrain and under tough conditions. Immense forces are created when the heavy equipment is in operation. The machinery must endure loads that can be possible miscreated by error of the operators. Those loads bring the tractors to operate outside of their normal operating conditions. So misuse loading simulations is a must in any product development cycle.

The effect of the truss thickness on the maximum stress in the arm.

Pipe safety assessment against thermal load.

Evaluate different types of snap joint: Cantilever, U-Shaped, Torsional and Annular
