Tutorial project for a flow analysis of a HVAC Ducting . The project only provides the geometry to start with. See our tutorials section to have a look at the step-by-step instructions to set up the simulation.

Thermal Comfort of an office space. Looking at how the air moves from the circular diffusers (note the coanda) and whether the occupants are comfortable.

Thermal comfort assessment of an office space using CFD with SimScale.

The goal of this project is to assess the natural ventilation inside a department store.

the effect of duct type and route on pressure drop

HVAC System for Cosmetic Grade Factory
Indonesia

Finally, I got the dimensions correct in this one. I think this is the fourth iteration.

This is the simulation of the first draft of the design of the cooling system based on the instructions given by the lab coordinator.

Row cooling of 6 server racks with a single cooling unit in the middle.

Validating CO level during normal operations

Based on youtube video: Ductwork sizing, calculation and design for efficiency: HVAC Basics and full worked example by The Engineering Mindset

HVAC project showcasing the modelling of louvres using the porous media concept.

The objective of this simulation is to show how CFD can be used to predict the flow from a ceiling fan in an indoor space in steady-state.  This can be used to demonstrate capability, or as a template for more complex problems in HVAC design.

In this tutorial, we will study the flow within an office.
After completion, we will understand the basics required to set up such an HVAC simulation and use the simulation to understand if the office workers will be comfortable.

practice to  impressionable fluid simulation  to check  CO2 level in Bedroom by using Passive scalar that represent to ppm
 base on garage fume extraction  example

condition: room size  4x5x2.7m  , 1 human sleep  , 1 fan , CO2 in air 400 ppm ,
time duration: 1000s  and 1 hour  ,CO2 of human 0.013  m3 per /h :: xxx ppm /sec

Internal flow and thermal analysis to understand the thermal comfort within a large atrium.  This is a typical example of the type of applications that our AEC customers perform on a regular basis.

This is a simple validation project of radiant cooling (HVAC), regarding the temperature gradient as well as the velocity profile inside a room

Analyse the duct positioning to have effective ventilation system

Simulate new duct design to increase comfort

Internal CFD study of air flow and thermal comfort.

Testing the boundary conditons for the heat load calulations of the  house with the known heat load.
House dimensions: 10x10x3 m
Wall thickness 150mm, wall thermal conductivity 0.038W/m/C
Tin: 20.5C, Tout: -35C
Heal load: 0.038/0.15*320*55.5 equals to 4500 Watt

The objective is to get insights of the flow field at the junction of the pipe
