Thermal Comfort of an office space. Looking at how the air moves from the circular diffusers (note the coanda) and whether the occupants are comfortable.

the effect of duct type and route on pressure drop

This project aims at analyzing and understanding how thermal comfort can be achieved in an office space of 4 occupants.
The scenario takes place in summer conditions ( 42C outside temperature and  65 relative humidity). The thermal comfort metric used in this project is predicted mean vote (PMV) and the target range is -0.5/0.5.
The original scenario results, where the external walls have a low insulation value and the inlet temperature is 19.85 degrees Celsius,  show exceeding PMV values (2.8 on average at the humans' surfaces) that are beyond the recommended ASHRAE-55-2017 values.
To improve the PMV values and the energy consumed in order to cool the occupants, the insulation value for the walls and windows were changed to reflect the impact of adding an insulation layer. The results of the improved scenario show a significant saving in energy spending whereas the thermal comfort of the occupant isn't changed significantly.
The next stage is to adjust and find an inlet temperature at a suitable level in order for the occupants to feel comfortable. The flowrate value wasn't modified because it would produce airspeed and therefore negatively impact the PMV values.
Working with a difference between the average room air temperature and the inlet temperature of 9 degrees Celsius, and aiming for a 22degres Celsius average room temperature as a starting point, an inlet of 14 degrees was used.
Simulation runs were performed at 14,13,12,11, and 10 deg Celsius until the measured PMV values for the occupants were all within the target range of (0.5/0.5). The  satisfactory condition scenario was determined to be with a 10 degrees Celsius inlet temperature.

HVAC System for Cosmetic Grade Factory
Indonesia

visualizing the differences in flow velocity, density, and thermal impact, making it easier to accurately identify the best solutions for optimizing the indoor climate.

Thermal Comfort in a small conference room - HVAC Design n. 1

analyses the duct positioning inside a theater, in order to have an effective ventilation system.

simulate the airflow from a duct of an automobile HVAC  system

To check that the pressure drop in the duct is not relatively much to affect performance. CFD

CFD analysis for displacement ventilation

MECHANICAL VENTILATION TO PROPOSED WAREHOUSE

This project is made for research purpose

The project goal was to find the best airflow around the operation theatre with a different Duct model.
so to achieve this goal, the duct was simulated with incompressible flow simulation type and then operation room was simulated with convection heat transfer simulation type.
At the end, The results of both duct design were compared and find the optimum duct design with respect to the operation room.
