I create simulation about circulation air of a office room

In this project I simulated convective heat transfer through a fin tube(Circular
fin of rectangular profile) made up of aluminium alloy. I prepared a CAD model
 of the required geometry.
Temperature function for the wall was applied as it carried hot fluid which
causes wall temperature of 200 degree celsius at entrance and 150 degree celsius
at exit. Then the value of convective heat transfer coefficient was defined (in
tabular form as “h” varied with temperature) and convection boundary
conditions were applied.
The heat transfer was solved using steady state heat conduction in cylindrical
co-ordinates.
 At the end
of simulation I was able to view the Temperature distribution and Total heat
flux generated  through the fin tube.
All the fin tube were at a constant temperature range as uniform rate of heat
transfer was occuring which validates its good design

Voir le rayonnement d'un mur plus ou moins épais

Thermal analyzing for an electronic system

تحليل انتقال الحرارة بالحمل الحر في الزعانف المثقبة والمصمتة

سنصمم أنابيب المياه والمكيف لتمثيل كيفية انتقال الحرارة

FFS-Pedemonte 7-Diemnsionamento Dry-cooler

To determine the thermal spread and required heating bands to maintain the temperature at the desired goal

Low voltage plate that is instaled in a transformator
