Flash Diffusivity via numerical analysis to model temperature evolution.

PCB heat analysis through Joule Heat transfer

FEA Analysis of a simple Microbolometer structure for MEEG640

Analysis of a fractal patterned plate heat exchanger using a conjugate heat transfer simulation

Weight comparision(gms)
Parameter					SPEC	Sample-01		Sample-02		Sample-03		Sample-04
Sample1					219.3±4.3	217.65		218.69		217.25		216.58
Dimensions
Parameter				Trial  Sample										Remark
View	Dimension 	SPEC (MM)	Tolerance (+ and -)	Sample -1
Top view 	Length	405.4	±2.0	402.83
	Width	183.8	±1.2	NA
	Handle width	27	±0.5	Not noted
	Hole spacing/size	13	±0.5	12.92
	Side height	121.2	±1.2	119.26
Front View 	Length	398.8	±1.2	NA
	Height (left side)	19.6	±0.5	20.01
	Small feature width	5.9	±0.3	3.5
	Thin section thickness	0.9	±0.2
	Vertical thickness	2.6	±0.2	2.53
	Another vertical section	1.6	±0.2	NA
	Top width (right side)	14.7	±0.5	14.54
	Vertical height (right)	7	±0.5	6.61
	Mid-section thickness	6.5	±0.5	6.25
	Bottom width (right)	10.5	±0.5	10.62
	Right feature width	25.1	±0.5	23.88
Right View 	Left vertical height	17.1	±0.5
	Small vertical section	18.2	±0.5	17.63
	Bottom left feature width	8.2	±0.5	8.16
	Bottom width (left side)	22	±0.5	20.91
	Top right thickness	2	±0.2	1.57
	Top right section width	3	±0.2	3.06
	Vertical thickness (right)	1.8	±0.2	1.87
	Small inner thickness	0.5	±0.2	NA
Bottom view	Width	60	±0.8	60.3
	Thickness	1.2	±0.2	1.26
	Small Feature Thickness	2.6	±0.2	2.12
	Top Edge Width	6.5	±0.5	6.52
	Section B-B Feature	5	±0.3	6.25
	Vertical Feature Height	1.8	±0.2	1.76

Update
Sim run1 was set up as Pressure inlet + Pressure outlet. I was told that this 'boundary condition combination is very poor in terms of stability'. I don't think the data is any good?
Sim run2 was set up as velocity inlet + pressure outlet. I was told this was better and should stop any diverging.

Does it flow?
It is a fluid heat transfer block/water boiler block. The block goes onto heat source, water gets pumped into it, and aim is to heat up the water.

To increase the surface area there are lots of fins inside, and fluid needs to turn 180, so the fins at the turn are in a radial pattern.

I wanted to simulate the water flow to see what it might do, and see if there are any massive dead spots.

Seems like there is a lot of interesting things going on.

study Air flow pattern and simulate turbulant areas inside a surgical operating theater

thermal simulation to analyse fluid flow,temperature distribution,heat flux,thermal stress and expansion and heat transfer

Analysing thermal properties by simulation

testing the enclosure for thermal dissipation

thermal analysis using simulation of cad model

Does it flow?

Made changes to model. Removed pins at the turn and put fins, removed some pins at the inlet and made also made inlet corners less round.

This sim was set up with Pressure inlet + Pressure outlet. I was told that this 'boundary condition combination is very poor in terms of stability'. I don't think the data is any good?

It is a fluid heat transfer block/water boiler block. The block goes onto heat source, water gets pumped into it, and aim is to heat up the water.

To increase the surface area there are lots of fins inside, and fluid needs to turn 180, so the fins at the turn are in a radial pattern.

I wanted to simulate the water flow to see what it might do, and see if there are any massive dead spots.

CFD simulation to observe the effects of biomimetic designs on the thermal efficiency of a plate heat exchanger.

Optimized Thermal Comfort for an International Level Sports Complex

Project goal is to analyze heat transfe.
Conjugate Heat Transfer. To analyze the thermal behavior of a lithium-ion battery pack under varying operating conditions and optimize its cooling system.
