In this study, a Venturi jet ejector was analyzed.  Water was used as a motive fluid, which creates a suction effect and vacuums the secondary flow into the ejector through the throat section.  Since one of the working fluid is water with relatively high Reynolds, the analysis was set for incompressible, Turbulent flow. As a result, the injector efficiency was calculated.
