A simple blower nozzle designed to fit the 16x20mm outlet of a 5015 blower common on 3D printers. My blower was measured to have a maximum static pressure of 18 mmH20 and is specified with a max CFM of at least 3. This nozzle is designed to give 15m/s outlet
velocity at 1.5 CFM  with 14 mmH20 static pressure, which should approximately match the load curve of my blower.

The goal of the project is to simulate airflow + static pressure of radial blower depending on the chosen rotor type.

BlowerRoom where Outlet massflow is defined with pipe and blower temperature defined, need to find what should be the inlet fan speed and volume.
