Industrial mixing tank example using the Multiphase solver.

In this example, a simple tank and a baffled tank design are compared in terms of mixing performance. The simulation involves 2-phases (air/water) and rotating parts (impellers).

As a final step, a sparger is implemented at the bottom of the tank, to simulate the tank aeration process.

This example is part of our free on-demand Multiphase webinar. Please register via the following link to watch how this case was setup inside the SimScale platform.
https://www.simscale.com/webinars-workshops/new-multiphase-flow-capabilities/

A 3 port 1/4 inch baffled manifold for normalized water flow out of 3 outputs from a single pressurized input

Analysis of flow patterns in a stirred tank using helical impeller with wall baffles
