CFD, Aerodynamics, Pressure points, Streamlines

The goal is to make a concept of a supersonic passenger jet that can meet the parameters I have set.

This jet is a business jet that can fly up to Mach 2.2

The goal is to test the temp and pressure of wings

Testing my new fabricated x-plane, prototype j1.

Aerodynamic of an electric stealth drone.

Análisis aerodinámico realizado sobre avión para el curso tópico profesional.

Comparison between balsa wood and spruce wood spar for a KFm3  4 meter span wing made of XPS blue foam for remote controlled aircraft.

I want to try plane simulation to test how air interact with the plane and see easier how   airplane flies in the sky.

Showing visualisation of simple wing ant different AOA

Structural Analysis of a UAV Wing with span of 4 meters

Structural analysis of remote controlled aircraft electric motor mount subjected to thrust force.

KFm3 Airfoil CFD Simulation for use on remote controlled aircraft.

Half-wing simulation of my aircraft design project

This project involves meshing externally a Boeing 777-200 LR Aircraft, and then simulating its' operation on flight facing an airflow with an axial velocity of 50 m/s.  It is one of the longest-range commercial airliners, with an exterior length and wingspan reaching 63.70 and 64.80 meters respectively.  For this case a model with removed engines was chosen in order to assist convergence and meshing. Also a Symmetry plane was added midst the Part, and half the part was used for meshing and simulation for simplification.  A steady state compressible flow simulation is executed to visualize the air flow around the bodywork and wings of the aircraft, as well as the pressure distribution while on flight.

Versione definitiva dopo dimensionamento della fusoliera del progetto PT01

Aircraft design project. Half-wing simulation.

This project important point of video shooting and very impressive photos click by drones camera

Ailerons are not made for liftoff, they help the plane turn. Ailerons are sections of the wing near the tip that can move up and down. This movement can increase or decrease lift. It can also increase or decrease drag. Ailerons work opposite of each other. This means, when one aileron moves up the other will move down. This way the airplane will roll in one direction. For example, when the aileron on the left wing moves up and the aileron on the right wing moves down the airplane will roll left.

In this project steady state incompressible fluid flow simulation of a small RC aircraft is performed for the completion of aircraft design course on SimScale's Academy. Two simulation at different AOA relative to wing is carried out to obtain the coefficient of lift and drag. Lift and drag forces are calculated at 3 and 20 AOA, also the flow around the aircraft is also visualized for the design consideration.

Model by bjorn rudgley on GrabCAD:
https://grabcad.com/library/mxs-r-redbull-air-racer-1

3D model modified in order to be used in CFD.

This project demonstrates the static stress analysis of three aircraft engine bearing bracket models considering both linear and nonlinear material definition. The models used in this analysis are taken from GrabCAD users who were the winners of GrabCAD 'Airplane Bearing Bracket Challenge'. The models are tested with horizontal and vertical loading conditions as provided on the challenge page of GrabCAD.
