Simulating airflow through an custom air box design to determine efficient inlet/outlet placement. Simulated using K-epsilon, a steady-state time dependency, and Newtonian air with 0 degree Celsius viscosity calculations.

Design a simple Radiator Airbox to improve airflow in engine bay.  Initial simulations will be ductwork modes.  Later may include full body flow to see turbulence from changes.

This project has the goal to analyze the inlet airflow in a Formula SAE's airbox car. Particularly I want to simulate the velocity vectors and the pressure of the airflow to understand where to improve the airbox geometry. This will be achieved with a punctual reporting of mass flow outing from mesh, that represents the mass flow entrance in the cylinder of the engine.
Final goal is to maximize the mass flow.
