This small project demonstrates capabilities of CHT solver and highlights important things to keep in mind when running a CHT case.
The objective of this project is to  help the users to  become familiar to use the CHT solverimplemented in SimScale. In this case, two ducts, containing air and water, go through a Heat Exchanger made by Silicon and Steel.
We will be able to see how the heat gets exchanged through the different media, and how air and water behave differently when they go through this type of Heat Exchangers.
The simulation will be turbulent and the steady-state of this system will be simulated. No transient behavior was taken into account. - Copy

Dapat menjelaskan dan mensimulasikan terkait heat exchange dengan menggunakan CHT pada panci

Tutorial project for a thermal analysis of a differential casing. The project only provides the geometry to start with. See our tutorials section to have a look at the step-by-step instructions to set up the simulation.
