CFD Analysis of water into Elliptical vessel

Simple heat transfer analysis for a beam, with a coarse  first order mesh. Results obtained for temperature at different points throughout the beam are in agreement with those from the hand-calculation.

Drone impact dynamics and 2 and 3 blade propeller configuration CFD study.

Incompressible Fluid Flow analysis of two globe valves to determine which is better in terms of pressure loss. The modified design does offer a pressure drop improvement and as such would be a better choice.

This project demonstrates the static stress analysis of three aircraft engine bearing bracket models considering both linear and nonlinear material definition. The models used in this analysis are taken from GrabCAD users who were the winners of GrabCAD 'Airplane Bearing Bracket Challenge'. The models are tested with horizontal and vertical loading conditions as provided on the challenge page of GrabCAD.

Linear static analysis to study von Mises stress in 3 configurations of an aircraft engine bracket under a vertical load.

Multiple Laminar flow analysis simulations with varying mesh fineness from automatic meshing, with other parameters kept constant. Flow phenomena like flow separation are better emulated as mesh fineness increases as expected, since the higher the number of domain cells in a mesh, the greater the flow detail that can be captured.

Linear static analysis of a square section beam for deflection due to a point load at one end with the other fixed, and comparing the results from different automatically generated meshes with the theoretical result to determine the best configuration for such a study.
The second order tet-dominant meshes out-perform the first order meshes, with the results getting closer to the theoretical as mesh fineness increases.
