Tubular Heat Exchangers:
Tubular heat exchangers are built of mainly of circular tubes although some other
geometry has also been used in different applications. This type of construction offers a large
amount of flexibility in design as the designing parameters like the diameter, length and the
arrangement can be easily modified. This type is used for liquid-to-liquid (phase changing
like condensing or evaporation) heat transfer. Again this type is classified into shell and tube,
double pipe and spiral tube heat exchangers.
Double Pipe Heat Exchanger:
The double pipe or the tube in tube type heat exchanger consists of one pipe placed
concentrically inside another pipe having a greater diameter. The flow in this configuration
cane be of two types: parallel flow and counter-flow. It can be arranged in a lot of series and
parallel configurations to meet the different heat transfer requirements. Of this the helically
arranged stands out as it has found its place in different industrial applications. As this
configuration is widely used, knowledge about the heat transfer coefficient, pressure drop,
and different flow patterns has been of much importance. The curvature in the tubes creates a
secondary flow, which is normal to the primary axial direction of flow. This secondary flow
increases the heat transfer between the wall and the flowing fluid. And they offer a greater
heat transfer area within a small space, with greater heat transfer coefficients. Study has been
done on the types of flows in the curved pipes, and the effect of Prandtl and Reynolds number
on the flow patterns and on Nusselt numbers. The two basic boundary conditions that are
faced in the applications are constant temperature and the constant heat flux of the wall.
